Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL0482 | 10 W | 97 CRI | max 37 V | 1300 lm | Ø173 x H118 mm | 15° 30° 50° | Ø150 mm | 300 mA |
| DL0483 | 18 W | 97 CRI | max 37 V | 1800 lm | Ø173 x H118 mm | 15° 30° 50° | Ø150 mm | 500 mA |
| DL0484 | 26 W | 97 CRI | max 37 V | 2600 lm | Ø173 x H118 mm | 15° 30° 50° | Ø150 mm | 700 mA |
- LED source
- Citizen
- Beam angles
- 15°, 30°, 50°
- Control
- Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP44
- Certifications
- CE
Photometry
DL0484. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 26 W
- Luminous flux
- 2,600 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 33,617 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 3,735 lx, Ø0.79 m
- Power
- 26 W
- Luminous flux
- 2,600 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 8,509 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 945 lx, Ø1.61 m
- Power
- 26 W
- Luminous flux
- 2,600 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 3,154 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 350 lx, Ø2.80 m
