Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| CH0271 | 5 W | 97 CRI | 230 V AC | 400 lm | Ø40 × 70 mm | 24° 36° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 24°, 36°
- Mounting
- Surface
- IP rating
- IP20
- Certifications
- CE
Photometry
CH0271. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 5 W
- Luminous flux
- 400 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 2,033 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 226 lx, Ø1.28 m
- Power
- 5 W
- Luminous flux
- 400 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 916 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 102 lx, Ø1.95 m
