Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| CH0122 | 13 W | 97 CRI | 230 V AC | 1300 lm | Ø110 × 60 mm | 100° | 2700, 3000, 4000 K |
| CH0123 | 16 W | 97 CRI | 230 V AC | 1600 lm | Ø145 × 60 mm | 100° | 2700, 3000, 4000 K |
| CH0124 | 26 W | 97 CRI | 230 V AC | 2600 lm | Ø185 × 60 mm | 100° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 100°
- Control
- Triac, DALI
- Mounting
- Surface
- IP rating
- IP20
- Certifications
- CE
Photometry
CH0124. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 26 W
- Luminous flux
- 2,600 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 964 cd
- At 3 m
- 107 lx, Ø7.15 m
