Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| CH0111 | 10 W | 97 CRI | 230 V AC | 1000 lm | Ø56 × 88 × 127 mm | 15° 24° 38° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 38°
- Mounting
- Surface
- IP rating
- IP20
- Certifications
- CE
Photometry
CH0111. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 1,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 12,930 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 1,437 lx, Ø0.79 m
- Power
- 10 W
- Luminous flux
- 1,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 5,083 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 565 lx, Ø1.28 m
- Power
- 10 W
- Luminous flux
- 1,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 2,060 cd
- Field angle (10%)
- 69.3°
- At 3 m
- 229 lx, Ø2.07 m
