Technical specifications
| Code | Watt | CRI | Voltage | Size | CCT | Notes |
|---|---|---|---|---|---|---|
| OUT-K1 | 10 W | 97 CRI | 36 V | Ø180 × 42 mm | 2700, 3000, 4000, 5000, 5700, 6500 K | 250 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000, 5000, 5700, 6500 K
- Control
- On/Off, Triac
- Mounting
- Surface, Wall
- IP rating
- IP65
Photometry
OUT-K1. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: estimated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 600 lm
- Efficacy
- 60 lm/W
- Peak intensity
- 191 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 21 lx, Ø10.39 m
