Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| C3-41242 heads | 40 W | 97 CRI | 220–240 V AC | 2 × 2000–2200 lm | Canopy 280 × 65 mm; heads Ø66 × 135 mm each | 10° 15° 24° 36° 50° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 10°, 15°, 24°, 36°, 50°
- Control
- On/Off, Triac, Casambi, DALI, 0–10 V
- Mounting
- Surface
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
C3-4124. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 40 W
- Luminous flux
- 619 lm
- Efficacy
- 15 lm/W
- Peak intensity
- 8,001 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 889 lx, Ø0.79 m
- Power
- 40 W
- Luminous flux
- 1,167 lm
- Efficacy
- 29 lm/W
- Peak intensity
- 5,932 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 659 lx, Ø1.28 m
- Power
- 40 W
- Luminous flux
- 1,485 lm
- Efficacy
- 37 lm/W
- Peak intensity
- 3,400 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 378 lx, Ø1.95 m
- Power
- 40 W
- Luminous flux
- 4,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 116,101 cd
- Field angle (10%)
- 18.2°
- At 3 m
- 12,900 lx, Ø0.53 m
