Technical specifications
| Code | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL14627 W 350 mA / 10 W 500 mA | 97 CRI | max 19 V | 580 / 960 lm | Ø80 x H79 mm | 15° 24° 36° 50° | 2700, 3000, 4000 K | Ø70 mm | 350 / 500 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°
- Mounting
- Recessed
- IP rating
- IP54
- Certifications
- CE
Photometry
DL1462. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Luminous flux
- 580 lm
- Peak intensity
- 7,499 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 833 lx, Ø0.79 m
- Luminous flux
- 580 lm
- Peak intensity
- 2,948 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 328 lx, Ø1.28 m
- Luminous flux
- 580 lm
- Peak intensity
- 1,328 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 148 lx, Ø1.95 m
- Luminous flux
- 580 lm
- Peak intensity
- 704 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 78 lx, Ø2.80 m
