Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| PH0085 | 3 W | 97 CRI | max 19 V | 250 lm | Ø150 × 150 mm | 15° 24° 36° 50° 60° | 2700, 3000, 4000 K | Ø76 mm | 180 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°, 60°
- Mounting
- Recessed, Surface, Suspended
- IP rating
- IP20
- Certifications
- CE
Photometry
PH0085. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 3 W
- Luminous flux
- 250 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 3,232 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 359 lx, Ø0.79 m
- Power
- 3 W
- Luminous flux
- 250 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 1,271 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 141 lx, Ø1.28 m
- Power
- 3 W
- Luminous flux
- 250 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 572 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 64 lx, Ø1.95 m
- Power
- 3 W
- Luminous flux
- 250 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 303 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 34 lx, Ø2.80 m
