Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT |
|---|---|---|---|---|---|---|
| PH0042 | 8 W | 97 CRI | 230 V AC | 600 lm | Tube Ø40 x L400 mm (opal part 300); canopy Ø60 × 55 mm; cable max 1700 mm | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Suspended
- IP rating
- IP20
- Certifications
- CE
Photometry
PH0042. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 8 W
- Luminous flux
- 600 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 191 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 21 lx, Ø10.39 m
