Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| PH0011 | 15 W | 97 CRI | 230 V AC | 1180 lm | Ø40 × 400 mm; canopy Ø65 × 100 mm; suspension 0–2000 mm | 24° 36° 60° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 24°, 36°, 60°
- Mounting
- Suspended
- IP rating
- IP20
- Certifications
- CE
Photometry
PH0011. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 15 W
- Luminous flux
- 1,180 lm
- Efficacy
- 79 lm/W
- Peak intensity
- 5,998 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 666 lx, Ø1.28 m
- Power
- 15 W
- Luminous flux
- 1,180 lm
- Efficacy
- 79 lm/W
- Peak intensity
- 2,701 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 300 lx, Ø1.95 m
- Power
- 15 W
- Luminous flux
- 1,180 lm
- Efficacy
- 79 lm/W
- Peak intensity
- 1,015 cd
- Field angle (10%)
- 109.4°
- At 3 m
- 113 lx, Ø3.46 m
