Technical specifications
| Code | Watt | CRI | Voltage | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| RE-XLight-0601 | 6 W | 97 CRI | 36 V | Ø71 × 70 mm | 22° 36° | 3000, 4000 K | Ø65 mm | 150 mA |
| RE-XLight-1201 | 12 W | 97 CRI | 36 V | Ø85 × 81 mm | 22° 36° | 3000, 4000 K | Ø75 mm | 300 mA |
| RE-XLight-1801 | 17 W | 97 CRI | 36 V | Ø95 × 86 mm | 22° 36° | 3000, 4000 K | Ø85 mm | 400 mA |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 22°, 36°
- Control
- On/Off, Triac
- Mounting
- Recessed
- IP rating
- IP20
Photometry
RE-XLight-1801. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: estimated from catalogue data, not measured.
- Power
- 17 W
- Luminous flux
- 1,275 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 7,700 cd
- Field angle (10%)
- 40.1°
- At 3 m
- 856 lx, Ø1.17 m
- Power
- 17 W
- Luminous flux
- 1,275 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 2,919 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 324 lx, Ø1.95 m
