Technical specifications
| Code | Watt | CRI | Voltage | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| TB300300 mm | 5 W | 97 CRI | 48 V DC | Ø16.5 × 300 × 126 mm | 100° | 2700, 3000, 4000, 5000 K |
| TB500500 mm | 10 W | 97 CRI | 48 V DC | Ø16.5 × 500 × 126 mm | 100° | 2700, 3000, 4000, 5000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000, 5000 K
- Beam angles
- 100°
- Control
- Casambi, DALI, Tuya, 0–10 V
- Mounting
- Magnetic track
Photometry
TB500. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: estimated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 600 lm
- Efficacy
- 60 lm/W
- Peak intensity
- 222 cd
- At 3 m
- 25 lx, Ø7.15 m
