Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| DL1917 | 10 W | 97 CRI | max 18 V | 560 lm | Ø73 × 70 mm | 2700, 3000, 4000 K | Ø68 mm |
| DL1917 | 13 W | 97 CRI | max 36 V | 900 lm | Ø73 × 70 mm | 2700, 3000, 4000 K | Ø68 mm |
| DL1918 | 10 W | 97 CRI | max 18 V | 560 lm | Ø68 × 70 mm (plates 125 × 75) | 2700, 3000, 4000 K | Ø76 mm |
| DL1918 | 13 W | 97 CRI | max 36 V | 900 lm | Ø68 × 70 mm (plates 125 × 75) | 2700, 3000, 4000 K | Ø76 mm |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
- Note
- 350 / 500 mA
Photometry
DL1917. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 13 W
- Luminous flux
- 900 lm
- Efficacy
- 69 lm/W
- Peak intensity
- 286 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 32 lx, Ø10.39 m
