Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT |
|---|---|---|---|---|---|---|
| TR017713–48° | 11 W | 97 CRI | 230 V AC | 730 lm | Ø50 × 140 mm; adapter L70 x W32 x H42 mm | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE
Photometry
TR0177. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 11 W
- Luminous flux
- 730 lm
- Efficacy
- 66 lm/W
- Peak intensity
- 232 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 26 lx, Ø10.39 m
