Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| TR0204 | 15 W | 97 CRI | 48 V DC | 1180 lm | L220 x W23 x H95 mm | 90° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 90°
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE, Class III
Photometry
TR0204. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 15 W
- Luminous flux
- 1,180 lm
- Efficacy
- 79 lm/W
- Peak intensity
- 508 cd
- Field angle (10%)
- 164°
- At 3 m
- 56 lx, Ø6.00 m
