Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| SL0032 | 7 W | 97 CRI | 24 V DC | 560 lm | Head Ø55 x L90 mm; overall H281 mm; stake length 158, stake Ø36 mm | 12° 24° 38° 50° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 12°, 24°, 38°, 50°
- Mounting
- Surface, Wall, Floor
- IP rating
- IP65
- Certifications
- CE
Photometry
SL0032. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 11,297 cd
- Field angle (10%)
- 21.9°
- At 3 m
- 1,255 lx, Ø0.63 m
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 2,847 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 316 lx, Ø1.28 m
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 1,154 cd
- Field angle (10%)
- 69.3°
- At 3 m
- 128 lx, Ø2.07 m
- Power
- 7 W
- Luminous flux
- 560 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 679 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 75 lx, Ø2.80 m
