Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| PH00731300 mm | 37 W | 97 CRI | max 36 V | 2160 lm | L1300 × Ø20 mm; suspension MAX.1700 mm | 50° | 2700, 3000, 4000 K | Ø76 mm | 900 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 50°
- Mounting
- Suspended
- IP rating
- IP20
- Certifications
- CE
Photometry
PH0073. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 37 W
- Luminous flux
- 2,160 lm
- Efficacy
- 58 lm/W
- Peak intensity
- 2,620 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 291 lx, Ø2.80 m
