Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1430 | 18 W | 97 CRI | max 37 V | 1800 lm | 100 × 100 × 64 mm | 15° 24° 38° 55° | 2700, 3000, 4000 K | Ø90 mm | 500 mA |
| DL1432 | 26 W | 97 CRI | max 37 V | 2600 lm | 136 × 136 × 83 mm | 15° 24° 38° 55° | 2700, 3000, 4000 K | Ø125 mm | 700 mA |
| DL1434 | 33 W | 97 CRI | max 37 V | 3800 lm | 158 × 158 × 96 mm | 15° 24° 38° 55° | 2700, 3000, 4000 K | Ø145 mm | 900 mA |
| DL1436 | 43 W | 97 CRI | max 37 V | 4300 lm | 180 × 180 × 109 mm | 15° 24° 38° 55° | 2700, 3000, 4000 K | Ø165 mm | 1200 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 38°, 55°
- Mounting
- Recessed
- IP rating
- IP65
- Certifications
- CE
Photometry
DL1436. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 43 W
- Luminous flux
- 4,300 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 55,597 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 6,177 lx, Ø0.79 m
- Power
- 43 W
- Luminous flux
- 4,300 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 21,858 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 2,429 lx, Ø1.28 m
- Power
- 43 W
- Luminous flux
- 4,300 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 8,858 cd
- Field angle (10%)
- 69.3°
- At 3 m
- 984 lx, Ø2.07 m
- Power
- 43 W
- Luminous flux
- 4,300 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 4,353 cd
- Field angle (10%)
- 100.2°
- At 3 m
- 484 lx, Ø3.12 m
