Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1396 | 2 W | 97 CRI | max 3 V | 160 lm | Ø37 x H51 mm | 30° | 2700, 3000, 4000 K | Ø34 mm | 700 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 30°
- Mounting
- Recessed, Wall
- IP rating
- IP67
- Certifications
- CE
Photometry
DL1396. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 2 W
- Luminous flux
- 160 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 524 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 58 lx, Ø1.61 m
