Technical specifications
| Code | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL0471 | 97 CRI | max 3 V, 24 V DC | 90 / 160 lm | Ø37 x H49 mm | 15° 24° 36° 60° | 2700, 3000, 4000 K | Ø34 mm | 350 / 700 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 60°
- Mounting
- Recessed, Wall
- IP rating
- IP67
- Certifications
- CE
Photometry
DL0471. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: measured with a goniophotometer where marked, otherwise calculated from catalogue data.
- Data
- Measured, 27 August 2025
- Power
- 0.8 W, 2700 K
- Luminous flux
- 26 lm
- Efficacy
- 33 lm/W
- Peak intensity
- 156 cd
- Beam angle (50%)
- 20.5°
- Field angle (10%)
- 39.2°
- At 3 m
- 17 lx, Ø1.09 m
- Data
- Measured, 29 August 2025
- Power
- 2 W, 3000 K
- Luminous flux
- 72 lm
- Efficacy
- 36 lm/W
- Peak intensity
- 340 cd
- Beam angle (50%)
- 23.7°
- Field angle (10%)
- 43.6°
- At 3 m
- 37 lx, Ø1.26 m
- Luminous flux
- 90 lm
- Peak intensity
- 1,164 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 129 lx, Ø0.79 m
- Luminous flux
- 90 lm
- Peak intensity
- 206 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 23 lx, Ø1.95 m
