Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| OL-KNSF24480T00-8A19 | 14.4 W | 97 CRI | 24 V | 1300 lm/m | 10 × 5 mm cross-section (PCB width 8 mm) | 147.8° | 2700, 3000, 4000, 6000 K |
| OL-INSF24480T00-8A19 | 14.4 W | 97 CRI | 24 V | 1330 lm/m | 10 × 5 mm cross-section (PCB width 8 mm) | 147.8° | 2700, 3000, 4000, 6000 K |
| OL-DNSF24480T00-8A19 | 14.4 W | 97 CRI | 24 V | 1320 lm/m | 10 × 5 mm cross-section (PCB width 8 mm) | 147.8° | 2700, 3000, 4000, 6000 K |
| OL-WNSF24480T00-8A19 | 14.4 W | 97 CRI | 24 V | 1330 lm/m | 10 × 5 mm cross-section (PCB width 8 mm) | 147.8° | 2700, 3000, 4000, 6000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000, 6000 K
- Beam angles
- 147.8°
- Mounting
- Recessed
- IP rating
- IP68
- Certifications
- CE, RoHS, UL
- Note
- Power per metre
Photometry
OL-KNSF24480T00-8A19. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 14.4 W
- Luminous flux
- 1,093 lm
- Efficacy
- 76 lm/W
- Peak intensity
- 268 cd
- At 3 m
- 30 lx, Ø20.79 m
