Technical specifications
| Code | CRI | Voltage | Flux | CCT | Cut-out |
|---|---|---|---|---|---|
| DL1865 | 97 CRI | 24 V DC | 20 / 40 lm | 2700, 3000, 4000 K | Ø80 mm |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Recessed, Wall
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1865. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Luminous flux
- 20 lm
- Peak intensity
- 6 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 1 lx, Ø10.39 m
