Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL1199 | 2 W | 97 CRI | max 3 V | 100 lm | Ø50 × 39 mm (flange); body Ø39/Ø43 × 55 mm | 2700, 3000, 4000 K | Ø40 mm | 700 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Recessed, Wall
- IP rating
- IP67
- Certifications
- CE
Photometry
DL1199. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: measured with a goniophotometer in the laboratory.
- Data
- Measured, 6 February 2026
- Power
- 3.2 W, 3000 K
- Luminous flux
- 36 lm
- Efficacy
- 11 lm/W
- Peak intensity
- 69 cd
- Beam angle (50%)
- 49.6°
- Field angle (10%)
- 65.6°
- At 3 m
- 7 lx, Ø2.77 m
