Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL1196 | 2 W | 97 CRI | max 3 V | 100 lm | Ø50 × 39 mm (flange); body Ø39/Ø43 × 55 mm | 2700, 3000, 4000 K | Ø40 mm | 700 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Recessed, Wall
- IP rating
- IP67
- Certifications
- CE
Photometry
DL1196. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 2 W
- Luminous flux
- 100 lm
- Efficacy
- 50 lm/W
- Peak intensity
- 32 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 4 lx, Ø10.39 m
