Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| S3-4212HLens | 30 W | 97 CRI | 2900–3000 lm | 90 × 105 mm | 10° 15° 24° 36° 50° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 10°, 15°, 24°, 36°, 50°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
S3-4212H. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 30 W
- Luminous flux
- 3,822 lm
- Efficacy
- 127 lm/W
- Peak intensity
- 4,636 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 515 lx, Ø2.80 m
- Power
- 30 W
- Luminous flux
- 2,900 lm
- Efficacy
- 97 lm/W
- Peak intensity
- 84,173 cd
- Field angle (10%)
- 18.2°
- At 3 m
- 9,353 lx, Ø0.53 m
- Power
- 30 W
- Luminous flux
- 2,900 lm
- Efficacy
- 97 lm/W
- Peak intensity
- 37,496 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 4,166 lx, Ø0.79 m
- Power
- 30 W
- Luminous flux
- 2,900 lm
- Efficacy
- 97 lm/W
- Peak intensity
- 14,741 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 1,638 lx, Ø1.28 m
