Technical specifications
| Code | Watt | CRI | Flux | Size | CCT |
|---|---|---|---|---|---|
| S3-1130FFlood | 50 W | 97 CRI | 7500–7600 lm | 1204 × 46 × 34 mm | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
S3-1130F. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 50 W
- Luminous flux
- 12,203 lm
- Efficacy
- 244 lm/W
- Peak intensity
- 4,524 cd
- At 3 m
- 503 lx, Ø7.15 m
