Technical specifications
| Code | Watt | CRI | Flux | Size | CCT |
|---|---|---|---|---|---|
| S3-1118FFlood | 30 W | 97 CRI | 2800–3000 lm | 481 × 65 × 33 mm | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
S3-1118F. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 30 W
- Luminous flux
- 2,800 lm
- Efficacy
- 93 lm/W
- Peak intensity
- 891 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 99 lx, Ø10.39 m
