Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| S3-1062 | 12 W | 97 CRI | 1000–1100 lm | 50 × 90 mm | 15° 24° 36° 50° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Magnetic track
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
S3-1062. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 12 W
- Luminous flux
- 531 lm
- Efficacy
- 44 lm/W
- Peak intensity
- 6,868 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 763 lx, Ø0.79 m
- Power
- 12 W
- Luminous flux
- 974 lm
- Efficacy
- 81 lm/W
- Peak intensity
- 4,950 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 550 lx, Ø1.28 m
- Power
- 12 W
- Luminous flux
- 1,087 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 2,488 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 276 lx, Ø1.95 m
- Power
- 12 W
- Luminous flux
- 1,000 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 1,213 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 135 lx, Ø2.80 m
