Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| DL195015–36° | 7 W | 97 CRI | max 20 V | 560 lm | Housing Ø55, plaster flange 113 × 64, barrel Ø28, heights 79 + 46 mm | 2700, 3000, 4000 K | Ø68 mm |
| DL192715–36° | 13 W | 97 CRI | max 36 V | 1040 lm | Trim Ø80, barrel Ø38, heights 94 + 64 mm | 2700, 3000, 4000 K | Ø76 mm |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
- Note
- 350 mA
Photometry
DL1927. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 13 W
- Luminous flux
- 1,040 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 331 cd
- Field angle (10%)
- 168.5°
- At 3 m
- 37 lx, Ø10.39 m
