Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1806 | 18 W | 97 CRI | max 36 V | 1440 lm | Housing Ø66, plaster flange 112, height 40, body Ø60 × 261, ring Ø110 mm | 55° | 2700, 3000, 4000 K | Ø68 mm | 500 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 55°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1806. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 18 W
- Luminous flux
- 1,440 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 1,458 cd
- Field angle (10%)
- 100.2°
- At 3 m
- 162 lx, Ø3.12 m
