Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL1607 | 5 W | 97 CRI | max 19 V | 450 lm | Ø40 x H28 mm above ceiling; head Ø26 x L70 mm | 15° 24° 36° | 2700, 3000, 4000 K | Ø35 mm | 250 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1607. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: measured with a goniophotometer where marked, otherwise calculated from catalogue data.
- Data
- Measured, 18 November 2025
- Power
- 5.5 W, 3000 K
- Luminous flux
- 340 lm
- Efficacy
- 62 lm/W
- Peak intensity
- 1,618 cd
- Beam angle (50%)
- 24.6°
- Field angle (10%)
- 42.6°
- At 3 m
- 172 lx, Ø1.31 m
- Power
- 5 W
- Luminous flux
- 450 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 5,818 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 646 lx, Ø0.79 m
- Power
- 5 W
- Luminous flux
- 450 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 1,030 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 114 lx, Ø1.95 m
