Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|---|
| DL15755 heads | 25 W | 97 CRI | 5 × max 19 V | 5 × 450 lm | 251 × 62 mm; heights 42 / 23, Ø26 mm head | 15° 24° 36° 50° | 2700, 3000, 4000 K | Ø245 mm | 250 mA; Power per head |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1575. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 25 W
- Luminous flux
- 2,250 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 29,092 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 3,232 lx, Ø0.79 m
- Power
- 25 W
- Luminous flux
- 2,250 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 11,437 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 1,271 lx, Ø1.28 m
- Power
- 25 W
- Luminous flux
- 2,250 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 5,150 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 572 lx, Ø1.95 m
- Power
- 25 W
- Luminous flux
- 2,250 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 2,729 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 303 lx, Ø2.80 m
