Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|---|
| DL1457200 mm stem | 13 W | 97 CRI | max 37 V | 1180 lm | Recessed body Ø50 × 31 mm; stem 200 mm; head Ø50 × 123 mm | 75° | 2700, 3000, 4000 K | Ø45 mm |
| DL1459400 mm stem | 13 W | 97 CRI | max 37 V | 1180 lm | Recessed body Ø50 × 31 mm; stem 400 mm; head Ø50 × 123 mm | 75° | 2700, 3000, 4000 K | Ø45 mm |
| DL1461400 mm stem | 13 W | 97 CRI | max 37 V | 1180 lm | Recessed body Ø50 × 31 mm; stem 400 mm; head Ø50 × 123 mm | 75° | 2700, 3000, 4000 K | Ø45 mm |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 75°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
- Note
- 350 mA
Photometry
DL1457. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 13 W
- Luminous flux
- 1,180 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 681 cd
- Field angle (10%)
- 136.7°
- At 3 m
- 76 lx, Ø4.60 m
