Technical specifications
| Code | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL13392 heads | 97 CRI | max 19 V | 2 × 630 lm | 168 × 90 x H85 mm; heads Ø40 mm | 15° 24° 36° 50° | 2700, 3000, 4000 K | Ø2 mm | 350 mA; Power per head |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE
Photometry
DL1339. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: measured with a goniophotometer where marked, otherwise calculated from catalogue data.
- Data
- Measured, 7 April 2025
- Power
- 17.8 W, 3000 K
- Luminous flux
- 1,158 lm
- Efficacy
- 65 lm/W
- Peak intensity
- 9,874 cd
- Beam angle (50%)
- 19.1°
- Field angle (10%)
- 35.4°
- At 3 m
- 1,073 lx, Ø1.01 m
- Data
- Measured, 7 April 2025
- Power
- 17.8 W, 3000 K
- Luminous flux
- 1,254 lm
- Efficacy
- 70 lm/W
- Peak intensity
- 6,741 cd
- Beam angle (50%)
- 24.3°
- Field angle (10%)
- 42.6°
- At 3 m
- 743 lx, Ø1.29 m
- Data
- Measured, 7 April 2025
- Power
- 17.8 W, 3000 K
- Luminous flux
- 1,419 lm
- Efficacy
- 80 lm/W
- Peak intensity
- 3,693 cd
- Beam angle (50%)
- 33.3°
- Field angle (10%)
- 58.7°
- At 3 m
- 408 lx, Ø1.79 m
- Luminous flux
- 1,260 lm
- Peak intensity
- 1,528 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 170 lx, Ø2.80 m
