Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| CH0203 | 7 W | 97 CRI | 230 V AC | 730 lm | Ø40 canopy x H40 mm; head Ø40 x L128 mm | 75° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 75°
- Mounting
- Surface
- IP rating
- IP20
- Certifications
- CE
Photometry
CH0203. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 7 W
- Luminous flux
- 730 lm
- Efficacy
- 104 lm/W
- Peak intensity
- 421 cd
- Field angle (10%)
- 136.7°
- At 3 m
- 47 lx, Ø4.60 m
