Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| R3-6454 | 20 W | 97 CRI | 2000–2100 lm | Ø70 × 145 mm | 15° 24° 36° 60° | 3000, 4000 K | Ø70 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 60°
- Control
- Triac, Casambi, DALI-2, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
R3-6454. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 20 W
- Luminous flux
- 808 lm
- Efficacy
- 40 lm/W
- Peak intensity
- 10,448 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 1,161 lx, Ø0.79 m
- Power
- 20 W
- Luminous flux
- 1,644 lm
- Efficacy
- 82 lm/W
- Peak intensity
- 3,764 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 418 lx, Ø1.95 m
- Power
- 20 W
- Luminous flux
- 2,554 lm
- Efficacy
- 128 lm/W
- Peak intensity
- 3,792 cd
- Field angle (10%)
- 82°
- At 3 m
- 421 lx, Ø2.49 m
- Power
- 20 W
- Luminous flux
- 2,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 10,166 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 1,130 lx, Ø1.28 m
