Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|---|
| R3-4011 | 6 W | 97 CRI | 220–240 V AC | 400–500 lm | Ø95 mm flange; stem Ø30 × 100 mm; 150 mm overall | 15° 24° 36° | 3000, 4000 K | Ø85 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 15°, 24°, 36°
- Control
- On/Off, Triac, Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
R3-4011. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 6 W
- Luminous flux
- 370 lm
- Efficacy
- 62 lm/W
- Peak intensity
- 1,212 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 135 lx, Ø1.61 m
- Power
- 6 W
- Luminous flux
- 400 lm
- Efficacy
- 67 lm/W
- Peak intensity
- 5,172 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 575 lx, Ø0.79 m
- Power
- 6 W
- Luminous flux
- 400 lm
- Efficacy
- 67 lm/W
- Peak intensity
- 2,033 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 226 lx, Ø1.28 m
- Power
- 6 W
- Luminous flux
- 400 lm
- Efficacy
- 67 lm/W
- Peak intensity
- 916 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 102 lx, Ø1.95 m
