Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| CX-9324 | 20 W | 97 CRI | 48 V | 2000 lm | Ø66 × 300 mm | 15° 24° 36° | 2700, 3000, 3500, 4000 K |
| CX-9325 | 28 W | 97 CRI | 48 V | 2800 lm | Ø73 × 300 mm | 20° 24° 36° | 2700, 3000, 3500, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 3500, 4000 K
- Beam angles
- 15°, 20°, 24°, 36°
- Control
- Casambi, DALI, 0–10 V, Bluetooth
- Mounting
- Magnetic track, Suspended
- IP rating
- IP20
- Certifications
- RoHS, CE
Photometry
CX-9325. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 28 W
- Luminous flux
- 2,800 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 20,429 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 2,270 lx, Ø1.06 m
- Power
- 28 W
- Luminous flux
- 2,800 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 14,233 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 1,581 lx, Ø1.28 m
- Power
- 28 W
- Luminous flux
- 2,800 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 6,409 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 712 lx, Ø1.95 m
