Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| P3-3026 | 50 W | 97 CRI | 4300–4400 lm | Ø151 x H180 mm | 15° 24° 38° 55° | 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 15°, 24°, 38°, 55°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Suspended
- IP rating
- IP65
- Certifications
- CE, RoHS, EMC, LVD
Photometry
P3-3026. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 50 W
- Luminous flux
- 3,410 lm
- Efficacy
- 68 lm/W
- Peak intensity
- 7,024 cd
- Field angle (10%)
- 69.3°
- At 3 m
- 780 lx, Ø2.07 m
- Power
- 50 W
- Luminous flux
- 5,215 lm
- Efficacy
- 104 lm/W
- Peak intensity
- 5,280 cd
- Field angle (10%)
- 100.2°
- At 3 m
- 587 lx, Ø3.12 m
- Power
- 50 W
- Luminous flux
- 4,300 lm
- Efficacy
- 86 lm/W
- Peak intensity
- 55,597 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 6,177 lx, Ø0.79 m
- Power
- 50 W
- Luminous flux
- 4,300 lm
- Efficacy
- 86 lm/W
- Peak intensity
- 21,858 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 2,429 lx, Ø1.28 m
