Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| P3-1350 | 50 W | 97 CRI | 5000–5100 lm | Ø90 × 300 mm | 10° 20° 30° 45° | 3000 K |
- LED source
- Citizen
- Colour temperature
- 3000 K
- Beam angles
- 10°, 20°, 30°, 45°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Suspended
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
P3-1350. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 50 W
- Luminous flux
- 1,842 lm
- Efficacy
- 37 lm/W
- Peak intensity
- 37,152 cd
- Field angle (10%)
- 21.9°
- At 3 m
- 4,128 lx, Ø0.63 m
- Power
- 50 W
- Luminous flux
- 2,856 lm
- Efficacy
- 57 lm/W
- Peak intensity
- 20,835 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 2,315 lx, Ø1.06 m
- Power
- 50 W
- Luminous flux
- 5,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 145,126 cd
- Field angle (10%)
- 18.2°
- At 3 m
- 16,125 lx, Ø0.53 m
- Power
- 50 W
- Luminous flux
- 5,000 lm
- Efficacy
- 100 lm/W
- Peak intensity
- 16,363 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 1,818 lx, Ø1.61 m
