Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| WL0140 | 3 W | 97 CRI | 230 V AC | 280 lm | 280, 35, 90, Ø26, 155, 35 mm | 24° 36° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 24°, 36°
- Mounting
- Surface, Wall
- IP rating
- IP20
- Certifications
- CE
Photometry
WL0140. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 3 W
- Luminous flux
- 280 lm
- Efficacy
- 93 lm/W
- Peak intensity
- 1,423 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 158 lx, Ø1.28 m
- Power
- 3 W
- Luminous flux
- 280 lm
- Efficacy
- 93 lm/W
- Peak intensity
- 641 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 71 lx, Ø1.95 m
