Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT |
|---|---|---|---|---|---|---|---|
| ML0008 | 20 W | 97 CRI | 230 V AC | 1800 lm | Ø200 x H1280 mm | 50° | 2700, 3000, 4000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 50°
- Mounting
- Floor
- IP rating
- IP20
- Certifications
- CE
Photometry
ML0008. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 20 W
- Luminous flux
- 1,800 lm
- Efficacy
- 90 lm/W
- Peak intensity
- 2,183 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 243 lx, Ø2.80 m
