Technical specifications
| Code | Watt | CRI | Voltage | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| PLA250250 mm | 2 W | 97 CRI | 48 V DC | Ø15.2 × 250 × 126 mm | 15° 24° | 2700, 3000, 4000, 5000 K |
| PLA300300 mm | 2 W | 97 CRI | 48 V DC | Ø15.2 × 300 × 126 mm | 15° 24° | 2700, 3000, 4000, 5000 K |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000, 5000 K
- Beam angles
- 15°, 24°
- Control
- Casambi, DALI, Tuya, 0–10 V
- Mounting
- Magnetic track, Suspended
Photometry
PLA250. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: estimated from catalogue data, not measured.
- Power
- 2 W
- Luminous flux
- 150 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 1,939 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 215 lx, Ø0.79 m
- Power
- 2 W
- Luminous flux
- 150 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 762 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 85 lx, Ø1.28 m
