Technical specifications
| Code | Watt | CRI | Voltage | Size | Beam | CCT |
|---|---|---|---|---|---|---|
| SU-HALO-R400 | 50 W | 97 CRI | 24 V | Ø406 × 35 mm | 60° 80° | 3000 K |
| SU-HALO-R600 | 90 W | 97 CRI | 24 V | Ø606 × 35 mm | 60° 80° | 3000 K |
- LED source
- Citizen
- Colour temperature
- 3000 K
- Beam angles
- 60°, 80°
- Control
- On/Off, Triac
- Mounting
- Surface
- IP rating
- IP20
Photometry
SU-HALO-R600. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: estimated from catalogue data, not measured.
- Power
- 90 W
- Luminous flux
- 6,750 lm
- Efficacy
- 75 lm/W
- Peak intensity
- 5,807 cd
- Field angle (10%)
- 109.4°
- At 3 m
- 645 lx, Ø3.46 m
- Power
- 90 W
- Luminous flux
- 5,400 lm
- Efficacy
- 60 lm/W
- Peak intensity
- 2,797 cd
- Field angle (10%)
- 145.8°
- At 3 m
- 311 lx, Ø5.04 m
