Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL12562 × 10 W | 20 W | 97 CRI | 2 × 960 lm | 165 × 85 x H94 mm | 15° 24° 36° 55° | 2700, 3000, 4000 K | Ø2 mm | 250 mA; Power per head |
| DL12562 × 13 W | 26 W | 97 CRI | 2 × 1180 lm | 165 × 85 x H94 mm | 15° 24° 36° 55° | 2700, 3000, 4000 K | Ø2 mm | 350 mA; Power per head |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 55°
- Mounting
- Recessed
- IP rating
- IP54
- Certifications
- CE
Photometry
DL1256. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 26 W
- Luminous flux
- 2,360 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 30,514 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 3,390 lx, Ø0.79 m
- Power
- 26 W
- Luminous flux
- 2,360 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 11,996 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 1,333 lx, Ø1.28 m
- Power
- 26 W
- Luminous flux
- 2,360 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 5,402 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 600 lx, Ø1.95 m
- Power
- 26 W
- Luminous flux
- 2,360 lm
- Efficacy
- 91 lm/W
- Peak intensity
- 2,389 cd
- Field angle (10%)
- 100.2°
- At 3 m
- 265 lx, Ø3.12 m
