Technical specifications
| Code | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out | Notes |
|---|---|---|---|---|---|---|---|---|
| DL1148 | 97 CRI | 24 V DC, max 3 V | 90 / 160 lm | Ø30 × 22 mm | 20° 40° 120° | 2700, 3000, 4000 K | Ø25 mm | 350 / 700 mA |
- LED source
- Citizen
- Colour temperature
- 2700, 3000, 4000 K
- Beam angles
- 20°, 40°, 120°
- Mounting
- Recessed
- IP rating
- IP44
- Certifications
- CE
Photometry
DL1148. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: measured with a goniophotometer where marked, otherwise calculated from catalogue data.
- Data
- Measured, 31 January 2026
- Power
- 1 W, 3000 K
- Luminous flux
- 22 lm
- Efficacy
- 22 lm/W
- Peak intensity
- 59 cd
- Beam angle (50%)
- 38.5°
- Field angle (10%)
- 48.7°
- At 3 m
- 6 lx, Ø2.10 m
- Luminous flux
- 90 lm
- Peak intensity
- 657 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 73 lx, Ø1.06 m
- Luminous flux
- 90 lm
- Peak intensity
- 168 cd
- Field angle (10%)
- 72.9°
- At 3 m
- 19 lx, Ø2.18 m
- Luminous flux
- 90 lm
- Peak intensity
- 27 cd
- At 3 m
- 3 lx, Ø10.39 m
