Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| D3-4244 | 10 W | 97 CRI | 400–450 lm | 50 × 83 mm | 24° 36° | 3000, 4000 K | Ø45 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 24°, 36°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
D3-4244. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 10 W
- Luminous flux
- 268 lm
- Efficacy
- 27 lm/W
- Peak intensity
- 1,364 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 152 lx, Ø1.28 m
- Power
- 10 W
- Luminous flux
- 400 lm
- Efficacy
- 40 lm/W
- Peak intensity
- 916 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 102 lx, Ø1.95 m
