Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| D3-4049 | 24 W | 97 CRI | 2000–2200 lm | 105 × 105 mm | 15° 24° 36° 50° | 3000, 4000 K | Ø95 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 15°, 24°, 36°, 50°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
D3-4049. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 24 W
- Luminous flux
- 1,088 lm
- Efficacy
- 45 lm/W
- Peak intensity
- 5,532 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 615 lx, Ø1.28 m
- Power
- 24 W
- Luminous flux
- 2,470 lm
- Efficacy
- 103 lm/W
- Peak intensity
- 2,996 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 333 lx, Ø2.80 m
- Power
- 24 W
- Luminous flux
- 2,000 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 25,859 cd
- Field angle (10%)
- 27.3°
- At 3 m
- 2,873 lx, Ø0.79 m
- Power
- 24 W
- Luminous flux
- 2,000 lm
- Efficacy
- 83 lm/W
- Peak intensity
- 4,578 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 509 lx, Ø1.95 m
