Technical specifications
| Code | Watt | CRI | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|
| D3-3008Reflector | 8 W | 97 CRI | 850–950 lm | Ø95 x H93.5 mm | 18° 24° 36° | 3000, 4000 K | Ø85 mm |
| D3-3008Reflector | 14 W | 97 CRI | 1500–1600 lm | Ø95 x H93.5 mm | 18° 24° 36° | 3000, 4000 K | Ø85 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 18°, 24°, 36°
- Control
- Triac, Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
D3-3008. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 14 W
- Luminous flux
- 428 lm
- Efficacy
- 31 lm/W
- Peak intensity
- 3,848 cd
- Field angle (10%)
- 32.8°
- At 3 m
- 428 lx, Ø0.95 m
- Power
- 14 W
- Luminous flux
- 813 lm
- Efficacy
- 58 lm/W
- Peak intensity
- 1,860 cd
- Field angle (10%)
- 65.6°
- At 3 m
- 207 lx, Ø1.95 m
- Power
- 14 W
- Luminous flux
- 1,500 lm
- Efficacy
- 107 lm/W
- Peak intensity
- 7,625 cd
- Field angle (10%)
- 43.7°
- At 3 m
- 847 lx, Ø1.28 m
