Technical specifications
| Code | Watt | CRI | Voltage | Flux | Size | Beam | CCT | Cut-out |
|---|---|---|---|---|---|---|---|---|
| D3-2020 | 28 W | 97 CRI | 220–240 V AC | 2700–2800 lm | Ø124 × 101 mm | 20° 30° 50° | 3000, 4000 K | Ø115 mm |
| D3-2020 | 35 W | 97 CRI | 220–240 V AC | 3700–3800 lm | Ø124 × 101 mm | 20° 30° 50° | 3000, 4000 K | Ø115 mm |
- LED source
- Citizen
- Colour temperature
- 3000, 4000 K
- Beam angles
- 20°, 30°, 50°
- Control
- On/Off, Triac, Casambi, DALI, 0–10 V
- Mounting
- Recessed
- IP rating
- IP20
- Certifications
- CE, RoHS, EMC, LVD
Photometry
D3-2020. Polar curve (C0–C180 solid, C90–C270 dashed, cd/klm) and key figures from the same data as the IES and LDT files: calculated from catalogue data, not measured.
- Power
- 35 W
- Luminous flux
- 2,039 lm
- Efficacy
- 58 lm/W
- Peak intensity
- 14,879 cd
- Field angle (10%)
- 36.5°
- At 3 m
- 1,653 lx, Ø1.06 m
- Power
- 35 W
- Luminous flux
- 4,333 lm
- Efficacy
- 124 lm/W
- Peak intensity
- 5,256 cd
- Field angle (10%)
- 91.1°
- At 3 m
- 584 lx, Ø2.80 m
- Power
- 35 W
- Luminous flux
- 3,700 lm
- Efficacy
- 106 lm/W
- Peak intensity
- 12,108 cd
- Field angle (10%)
- 54.7°
- At 3 m
- 1,345 lx, Ø1.61 m
